190mm 220mm 280mm LED COB Downlight with 50,000 Hours Lifespan Die-casting Aluminum Heatsink and CCT Changeable for Office

Brand Name:	HS
Model Number:	HS-DL-C-190-ND
MOQ:	30
Price:	Negotiation

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS

Document:

Datasheet for LED Downlight...es.pdf

Wattage:

20W

Light Type:

LED COB

Beam Angle:

60°

Light Color:

White

Input Voltage:

AC200-240V

Lifespan:

50,000 Hours

Color Temp.:

3000K/4000K/5000K/6000K/CCT Changeable

CRI:

80Ra

Dimming Type:

Non Dimmable/Triac/ 0-10V/ DALI/Zigbee 3.0

Warranty:

5 Years

Highlight:

White LED Grow Lights

LED Grow Lights 100 Watt

Indoor Gardening Grow Lights

Product Description

This LED Downlight is a high-performance and cost-effective lighting solution designed for commercial, retail, office, and architectural lighting projects.

Featuring a die-casting aluminum heatsink, tempered glass with a frosted center, and a unique lightweight structure, it delivers excellent heat dissipation, long lifespan, and enhanced visual comfort with reduced glare. Equipped with high-quality COB LED technology compliant with LM-80 standards, it ensures low lumen decay and stable brightness performance throughout its lifetime.

Powered by a top-brand constant current LED driver with an isolated solution, this downlight provides safe, reliable, and efficient operation. Its economical design makes it ideal for large-scale lighting projects, while multiple dimming options including non-dimmable, TRIAC, 0-10V, and DALI offer flexible lighting control solutions.

190mm 220mm 280mm LED COB Downlight with 50,000 Hours Lifespan Die-casting Aluminum Heatsink and CCT Changeable for Office 0

Technical Specifications

Model NO.	HS-DL-C-190-XD	HS-DL-C-220-XD	HS-DL-C-280-XD
Dimensions	φ190x110mm	φ220x125mm	φ280x146mm
Cutout	170mm	195mm	250mm
Power	20W	30W	40W
Luminous Flux	2000LM	3000LM	4000LM
Luminous Efficiency	100LM/W
Input Voltage	AC200-240V, 50/60Hz
Power Factor	>0.9
Color Temp.	3000K/4000K/5000K/6000K/CCT Changeable
CRI	80Ra
SDCM	SDCM<5
Lifespan	L80B10=100,000 Hours
Beam Angle	60°/90°
Dimming Type	Non Dimmable/Triac/0-10V/DALI/Zigbee 3.0/Blue Tooth
IP Rating	IP20
Main Materials	Die-casting Aluminum + Glass
Working Temperature	-20℃ ~ +40℃
THD	<15%
Insulation Class	CLASS II
Safety Standards	EN IEC60598-2-1
EMC	EN 55015, EN IEC 61000-3-2
Certificate	CE RoHS
Warranty	5 Years

FAQ

Q1:

Can you provide OEM service?

Yes, we support OEM/ODM customization.

Q2:

What is your MOQ?

Usually 100pcs, negotiable for projects.

Q3:

Do you provide certificates?

Yes, CE and RoHS certificates available.

Q4:

Can you provide samples?

Yes, samples are available.
